News Feed

September 2019

Warsash Scientific are now the Australian distributor for Foster + Freeman

FROM Foster + Freeman

Posted: 13 September 2019

Foster + Freeman instruments for forensic examination
Foster + Freeman advanced instruments for forensic exvidence detection, collection and analysis.

Warsash Scientific are now the Australian and New Zealand distributor for Foster + Freeman. Foster + Freeman design and manufacture market leading systems for the examination of questioned documents, latent fingerprints, trace evidence and shoe prints.

Established in 1978, Foster + Freeman has become one of the foremost forensic science equipment suppliers in the world, exporting marketin-leading, and in many cases unique products to more than 150 countries.


August 2019

Ultra-efficient ns and ps solid state lasers

FROM Photonics Industries

Posted: 1 August 2019

Ultra-efficient ns and ps solid state lasers
Ultra-efficient ns and ps solid state lasers from Photonics Industries.

Photonics Industries, the pioneer of intracavity solid-state harmonic lasers, has introduced its new DX Series, the highest wall plug efficiency nanosecond (ns) laser:

  • 17% for green wavelengths
  • 10% for UV wavelengths

Concurrently, Photonics Industries has introduced its new RX Series, the Highest Pulse Energy pico second (ps) laser in the market ~1mJ in IR, over 400uJ in Green and ~200uJ in UV:

  • High power (up to 100W in IR)
  • Short pulse (10ps)
  • High repetition rates (up to 8MHz)
  • The most compact rugged All-in-one ps laser
  • The highest efficiency ps laser with the lowest power consumption

Such high pulse energies allow for process efficiency optimization by spatial scaling as the beam can be split numerous times to simultaneously feed multiple work stations yielding the lowest Cost of Ownership. Combined with increases in wall plug efficiencies, industrial micromachining customers can manufacture their products at a much quicker, more efficient rate, expediting their manufacturing processes thus reducing the cost and increasing availability of next gen technologies to a greater cross section of the world’s population.


P-725 objective scanner

FROM Physik Instrumente

Posted: 1 August 2019

P-725 objective scanner
P-725 objective scanner from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched the P-725.1Cx PIFOC objective scanner.

The P-725.1Cx is the latest generation in the PIFOC objective scanner series with increased stiffness for faster settling times and increased lifetime.

Key features include:

  • Fine positioning of objectives with sub0nm resolution
  • Significantly faster response and higher lifetime than motorised positioners
  • Zero-play, high precision flexure guide system for better stability
  • Compatible with MetaMorph imaging software

Key application areas include:

  • Super-resolution microscopy
  • Confocla microscopy
  • 3D imaging
  • Interferometry
  • Semiconductor inspection

April 2019

785nm STM laser for Raman

FROM Cobolt

Posted: 1 April 2019

785nm STM laser for Raman
785nm STM laser for Raman from Cobolt.

Cobolt, a part of HÜBNER Photonics, introduces the addition of a new wavelength of 785 nm single transverse mode (STM) to the Cobolt 08-01 Series of frequency stabilized, narrow linewidth lasers.

With up to 120 mW and a linewidth of <20 pm, the Cobolt 785nm is ideal for Raman spectroscopy and imaging applications with an integrated optical isolator and spectral filter. The Cobolt 785nm STM complements Cobolt’s current offering of narrow linewidth laser diodes; 405 nm, 457 nm, 473 nm, 515 nm, 532 nm, 561 nm, 633 nm, 660 nm and 1064 nm.

All Cobolt lasers are manufactured using proprietary HTCure™ technology and the resulting compact hermetically sealed package provides a very high level of immunity to varying environmental conditions along with exceptional reliability. With demonstrated lifetime capability of >60 000 hours and several thousand units installed in the field, Cobolt lasers have proven to deliver unmatched reliability and performance both in laboratory and industrial environments and are offered with market leading warranty terms.


Highest efficiency high pulse energy diode laser

FROM Photonics Industries

Posted: 1 April 2019

High efficiency DP series pulsed diode laser
High efficiency DP series pulsed diode laser from Photonics Industries.

Photonics Industries, the pioneer of intracavity solid-state harmonic lasers, has introduced a new line of pulsed diode pumped lasers, the DP Series, for applications that need; short pulses (<10ns), high pulse energy with low power consumption, and air cooling. The DP series has several standard lasers available with up to:

  • 20mJ at 1,053nm
  • 18mJ at 527nm
  • 4mJ at 351nm

All with a TEM00 mode quality at high repetition rates (up to 200Hz) in a compact, industrial grade, small all-in-one form factor. Also, the high rep rate version, the DP2K Series, fit applications that require high pulse energies at up to 2kHz rep rates with low power consumption. The DP2K Series is available in IR (1,064nm), green (532nm) and/or DUV (266nm).

Industrial and research laser based material processing applications include:

  • Miromachining/ablationo
  • Pulsed laser deposition
  • Laser cleaning
  • Harmonic and parametric pumping
  • Laser induced breakdown psectroscopy (LIBS)
  • Laser induced fluorescence (LIF)
  • THz generation
  • PIV
  • Nonlinear spectroscopy

Sprout-H 532nm 18W pump laser

FROM Lighthouse Photonics

Posted: 1 April 2019

Sprout-H 532nm 18W pump laser
Sprout-H 532nm 18W pump laser from Lighthouse Photonics.

Lighthouse Photonics announce the release of the Sprout-HTM, a compact, modular, diode‐pumped solid‐state (DPSS) laser providing up to 18 Watts continuous‐wave (CW) power at 532nm in a near perfect TEMoo mode with extremely low optical noise and excellent long‐term stability.

Sprout‐H is truly a next‐generation laser designed and manufactured using many years of experience to provide a sealed, turn‐key source of collimated green light with high spectral purity. There are 7 versions available ranging from 5 Watts to 18 Watts. The laser head is a monolithic 3‐dimensional design for ruggedness and compactness. The pump diode, integrated inside the laser head, has a typical mean time to failure (MTTF) of more than 50,000 hours to minimize cost‐of ownership. The laser head can be disconnected from the control cable for easy integration. The power supply contains an integrated thermo‐electrically‐cooled (TEC) chiller.


February 2019

Large area CMOS beam profiler

FROM DataRay

Posted: 1 February 2019

Large area CMOS beam profiler
Large area CMOS beam profiler fromDataRay.

DataRay, a global pioneer in the design and manufacture of laser beam profilers has launched the TaperCamD-LCM large area CMOS beam profiler.

The TaperCamD-LCM large area CMOS beam profiler includes industry leading features such as 25 x 25 mm active area, 12.5 μm (effective) pixels and port powered USB 3.0. With a 25,000:1 electronic auto-shutter (79 μs to 2 s) the TaperCamD is suitable for both CW and pulsed laser profiling.

Key features include:

  • 355 to 1,150 nm wavelength range
  • 4.2 MPixel, 2,048 x 2,048 pixels, 12.5 μm pixels (effective)
  • 25 x 25 mm active area
  • HyperCalTM – dynamic noise and baseline correction
  • Isolated pulse triggering and parallel capture

L-408 compact linear stage

FROM Physik Instrumente

Posted: 1 February 2019

L-408 compact linear stage
L-408 compact linear stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched the L-408 compact linear stage.

The L-408 linear stage family with crossed roller guides and anti-creep system offer exceptional stiffness and smooth running ideally suited for industrial and scientific applications. The inherent stiffness of the crossed roller guides allows for smoother running, higher guiding accuracy and a load capacity of 20kg.

Key features include:

  • 25mm travel range
  • Stepper of DC motor options
  • Minimum step size of 100 nm or 500 nm
  • Crossed roller guide with anti-creep system
  • Integrated Hall effect reference and limit switches

Pulsed laser power measurement system

FROM Labsphere

Posted: 1 February 2019

Pulsed laser power measurement system
Pulsed laser power measurement system from Labsphere.

Labsphere’s Pulsed Laser Power Measurement Systems assure an accurate, reproducible method of determining the total power from a collimated or divergent laser or laser diode. The unique geometry of the sphere means that laser power measurements are independent of beam polarisation and are insensitive to beam alignment.

The systems provide options for laser power measurement over the 350 to 1,700nm wavelength region for optical powers ranging from nW to hundreds of Watts. The system’s calibrations are traceable to the National Institute of Standards and Technology (NIST). Each system consists of a laser power measurement sphere, post holder and base assembly, a detector assembly, and multi-wavelength calibration.


December 2018

Combined laser diode and temperature controller

FROM Wavelength Electronics

Posted: 15 December 2018

Laser diode and temperature controller
Combined laser diode and temperature controller from Wavelength Electronics.

The LDTC Laser Diode Driver and Temperature Controller combines Wavelength Electronics proprietary FL500 and highly stable WTC3243 in one compact module. LDTC modules are in use around the world providing trouble-free reliability in range finders, telecom laser modules, military-aerospace research and development, airborne metrology, academic research, laser diode LIV testers, and more.

The laser driver is based on our popular FL500, known for low noise output and trouble-free operation. Two models are available, providing either 500 mA (LDTC0520) or 1.0 A output current (LDTC1020). The current limit circuit cleanly clamps laser diode current without ringing or overshoot, and recovers without inducing a phase shift in a modulated laser signal.

The temperature controller is designed around the WTC3243, our ultra-stable temperature control module known for the ability to sweep load temperature across ambient. Independent cooling- and heating-current limits allow the LDTC to be used with thermoelectric coolers or resistive heaters and either negative or positive temperature coefficient sensors.

Remote computer control is available using the USBKIT, which also allows graphing and datalogging.


L-505 compact linear stage

FROM Physik Instrumente

Posted: 15 December 2018

L-505 compact linear stage
L-505 compact linear stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched the L-505 compact linear stage.

The L-505 linear stage family with four-row ball guides designed for comparatively high load ratings , exceptional stiffness and smooth running is ideally suited for industrial and scientific applications. With options for flange-mounted or folded drivetrains the L-505 is a compact linear stage platform that can easily be combined for X, Y and Z axis applications.

Key features include:

  • 13 or 26mm travel range
  • Stepper of DC motor with or without gearhead
  • Incremental linear encoder with a resolution of 5nm (stepper) or 50nm (DC)
  • Back-lash compensated preloaded leadscrew

S-335 fast tip/tilt platform

FROM Physik Instrumente

Posted: 15 December 2018

S-335 fast tip/tilt platform
S-335 fast tip/tilt platform from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched the S-335 fast tip/tilt platform.

The S-355 tip/tilt platform utilise zero-play flexure guides which offer high guiding accuracy and are free of maintenance, friction and wear. Their stiffness allows for high load capacity and they are insensitive to shock and vibrations. The parallel-kinematic multi-axis system with minimal mass inertial design allows for fast, dynamic precise motion.

Key application areas include:

  • Image processing/stabilisation
  • Optical trapping
  • Laser scanning/beam steering
  • Laser tuning
  • Beam stabilisation

October 2018

VIS and IR high power fibre lasers

FROM AzurLight Systems

Posted: 5 October 2018

High power fibre laser
VIS and IR high power fibre lasers from AzurLight Systems.

AzurLight Systems introduces the unique series of high power all fibre laser solutions for greatly improved stability, robustness and unprecedented system integration. The single frequency mode visible and infrared lasers offer unique performance in terms of low noise and high power, combined with the inherent efficiency and stability of fibre lasers.

Standard wavelengths available include 1064, 1030 and 976nm with up to 50W of power in the infrared and 532, 515 and 488nm with up to 10W of power in the visible. Other wavelengths are available on request using an external seed laser, including the customers own seed laser.

Key applicatin areas are:

  • Atom trapping
  • Atom cooling
  • Bose-Einstein condensates
  • Laser pumping
  • Holography
  • Interferometry
  • Spectroscopy

Four channel single photon counting module

FROM Excelitas

Posted: 5 October 2018

four channel SPCM
Four channel single photon counting module from Excelitas.

Excelitas Technologies introduces the all new high performance four channel single photon counting modules (SPCM). Excelitas Technologies is a global leader focused on delivering innovative, customised optoelectronics solutions.

Excelitas Technologies have extended it’s portfolio of low-light-level detection modules with a multi-channel version of the well-known SPCM single photon counting module that is based on a unique silicon avalanche photodiode (SLiK) that has a circular active area of 180μm with a peak photon detection efficiency exceeding 60% at 650nm. Each photodiode is both thermoelectrically cooled and temperature controlled, ensuring stabilized performance despite changes in the ambient temperature.

The SPCM-AQ4C card uses an improved circuit with a peak count rate >4 M c/s for short bursts of time on all 4 channels and a count rate of 1.5 M c/s for continuous operation. There is a "dead time" of 50 nanoseconds (ns) between pulses. The module requires +2 Volts, +5 Volt, and +30 Volt power supplies. The output of each channel – a TTL pulse that is 4.5 Volts high (into a 50 Ω load) and 25 ns wide – is available at the card edge behind the circuit board. Each TTL pulse corresponds to a detected photon.


F-122 5-axis fibre alignment system

FROM Physik Instrumente

Posted: 5 October 2018

F-122 fibre alignment system
F-122 5-axis fibre alignment system from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched F-122 5-axis fibre alignment system.

The setup of the fibre alignment system consists of three M-122 series motorised linear stages and the WT-85 and WT-100 goniometers. In conjunction with the C-884.6DC controller and C-990.FA1 software it is possible to use the F-122 as a fully automated alignment system for light-transmitting components with the integration of an optical intensity signal. Synchronised operation of the axes is possible which allows for one- or two-dimensional motion paths including spiral paths.


August 2018

640nm single frequency laser

FROM Cobolt

Posted: 7 August 2018

Single frequency laser
640nm single frequency laser from Cobolt.

Cobolt introduces the addition of a new wavelength of 640 nm to the Cobolt 05-01 Series of single frequency lasers. With up to 500 mW and a linewidth of <1 MHz, the Cobolt Bolero is ideal for holographic and advanced interferometric applications. The Cobolt Bolero complements Cobolt's current offering of RGB single frequency lasers: Cobolt Flamenco 660 nm with up to 500 mW, Cobolt Samba 532 nm with up to 1.5 W and Cobolt Twist 457 nm with up to 200 mW.

All Cobolt lasers are manufactured using proprietary HTCure technology and the resulting compact hermetically sealed package provides a very high level of immunity to varying environmental conditions along with exceptional reliability. With demonstrated lifetime capability of >60 000 hours and several thousand units installed in the field, Cobolt lasers have proven to deliver unmatched reliability and performance both in laboratory and industrial environments and are offered with market leading warranty terms.

Read Article

L-306 compact Z stage

FROM Physik Instrumente

Posted: 7 August 2018

Compact Z stage
L-306 compact Z stage from Physik Instrumente.

Physik Instrumente a global leader in the design and manufacture of high precision motion control systems has launched the L-306 compact Z stage.

The L-306 is a new series of compact Z stages with drive screw, a maximum travel range of 13mm for loads up to 2kg and a footprint of 63x63mm. Motor options include 2-phase stepper, 2-phase stepper with incremental encoder or DC motor with incremental encoder. Key features include:

  • Travel range: 13mm
  • Minimum incremental motion: 2.5μm (0.1μm with encoders)
  • Velocity: 5mm/s
  • Bidirectional repeatability: ±2μm (0.5μm with encoders)
  • Load capacity: 20N
  • 63 x 63mm footprint
Read More

TMS1200 high performance optical profiler

FROM Polytec

Posted: 7 August 2018

TMS1200 optical profiler
TMS1200 optical profiler from Polytec.

The new Polytec TMS-1200 TopMap μ.Lab, allows characterisation of surfaces and microstructures with a very high lateral resolution. The optical profilometer determines parameters such as texture, flatness, ripple and roughness on both fine and sensitive structures. The Polytec Smart Surface scanning technology even measures areas of a surface with different reflectivity’s.

Individual images are stitched together with ease using an optional, motorized XY positioning stage. Key features include:

  • Non-contact measurement of microstructures and sensitive surfaces
  • 3D topography measurement and roughness determination with nm resolution
  • Determines film thickness and surface defects
  • Excellent lateral resolution for rough and reflective surfaces
  • Smart Surface Scanning technology measures even on high-contrast surfaces
  • 2D and 3D presentation modes with video overlay
  • Application-specific objectives (including LWD objectives for vacuum chambers)
Read More

X-1100 high-intensity pulsed light system

FROM Xenon

Posted: 7 August 2018

X-1100 high intensity pulsed light system
X-1100 high intensity pulsed light system from Xenon.

The XENON X-1100 is the only low-cost benchtop Pulsed Light system that enables researchers to more easily characterize new processes using XENON’s proven technology.

The X-1100 is a low-cost benchtop research tool that boasts powerful performance and functionality, yet is easy to use. Applications that require intense light, such as photonic curing, sterilization and sintering can benefit from the broadband photonic source offered by the X-1100. This compact system allows users to experiment with Pulsed Light in small area applications with the confidence in reusing the configuration data in defining larger scale or production systems offered by XENON.

Read More

Wireless spectrometry

FROM Stellarnet

Posted: 7 August 2018

X-1100 high intensity pulsed light system
X-1100 high intensity pulsed light system from Xenon.

Now available for all Stellarnet spectrometers, the zAP2 upgrade adds an integrated wireless CPU with Wifi access to your spectrometer. This feature allows you to cut the cord and access multiple spectrometers around your facility at once!

Additionally, on board computing offers the capability to automate and stream applications and turn your spectrometer into a portable wireless analyzer with real world data output such as % concentration, CIELAB color values, UV or total light power, or just about anything you can dream of.

Read More

June 2018

Single frequency ultra low noise 532nm DPSS laser

FROM Lighthouse Photonics

Posted: 9 May 2018

532nm laser
Single frequency ultra low noise 532nm DPSS laser from Lighthouse Photonics.

Lighthouse Photonics announce the release of the Sprout Solo, a single frequency, ultra-low noise, high power CW 532nm diode pumped solid-state (DPSS) laser with up to 10W output power. The Sprout Solo produces near-perfect spatial beam quality with extremely high power stability and is specifically designed for application that require high quality performance.

The laser head is a monolithic 3-dimensional design for ruggedness and compactness to minimize the space consumed in your lab or instrument. The fiber-coupled pump diode package contained in the power supply has a typical mean time to failure of more than 50,000 hours.

Read Article

Laser wavelengths for Raman

FROM Cobolt

Posted: 9 May 2018

Laser diodes
Laser wavelengths for Raman from Cobolt.

Cobolt introduces new wavelengths on the 08-01 Series of 457 nm, 473 nm, 515 nm, 660 nm and 1064 nm, complementing already available wavelengths of 405 nm, 532 nm, 561 nm and 785 nm. The 08-01 series of single frequency and narrow linewidth lasers are ideal for Raman spectroscopy applications.

The 08-01 Series consists of high performance, ultra-compact, single longitudinal mode (SLM) diode pumped lasers (08-DPL) up to 400 mW and narrow linewidth diode lasers (08-NLD) up to 500 mW, all having exceptional wavelength stability and spectral purity. With totally integrated electronics, an integrated optional optical isolator and clean up filter, the lasers from the 08-01 Series are easily integrated into high end Raman based systems or other analytical instrumentation.

Read Article

High load linear stage

FROM Physik Instrumente

Posted: 9 May 2018

High load linear stage
L-412 high load linear stage from Physik Instrumente.

Physik Instrumente a global leader in the design and manufacture of high precision motion control systems has launched the L-412 high-load linear stage.

The L-412 linear stage family with precision ball screws is ideally suited for industrial and scientific applications. High-performance synchronous servo motors, heavy-duty recirculating ball bearings and precision rotary and linear encoders ensure high performance, reliability and long lifetimes. Key features include:

  • Travel range: 52, 102, 204, 305, 407, 508 and 610mm
  • Various rotary and linear encoder options, either absolute or incremental
  • Optional holding brake
  • Optional drag chain
Read More

V-508 PIMag linear stage

FROM Physik Instrumente

Posted: 9 May 2018

V-508 PiMag linear stage
V-508 PIMag linear stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched V-508 PIMag magnetic drive compact linear stage.

The PIMag magnetic direct drive does not use mechanical components in the drivetrain, with it's 3-phase magnetic drive transmitting the drive force directly to the motion platform without friction. The V-508 has the following key features:

  • Travel range: 80, 170 and 250mm
  • Resolution: 78nm
  • Incremental or absolute encoders
  • Minimum incremental motion: 0.5nm
  • Velocity: 1 m/s
  • Bidirectional repeatability: ±50nm
  • Load capacity: 100N
Read More

V-738 PIMag high precision XY stage

FROM Physik Instrumente

Posted: 9 May 2018

V-738 PiMag high precision XY stage
V-738 PIMag high precision XY stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched V-508 PIMag magnetic drive compact linear stage.

The PIMag magnetic direct drive does not use mechanical components in the drivetrain, with it's 3-phase magnetic drive transmitting the drive force directly to the motion platform without friction. The V-738 has the following key features:

  • Travel range: 102 x 102mm
  • Resolution: 1nm
  • Incremental linear encoders
  • Minimum incremental motion: 20nm
  • Velocity: 0.5m/s
  • Bidirectional repeatability: ±25nm
  • Load capacity: 100N
  • 150 x 150mm clear aperture
Read More

April 2018

Drug Hunter mode for the detection of fentanyls

FROM 908 Devices

Posted: 27 March 2018

Fentanyl detection
Drug Hunter mode for the detection of fentanyls from 908 Devices.

908 Devices continues to expand capability, providing real-time solutions to real-world problems.

908Devices introduces the new Drug Hunter Mode on the MX908 in response to the opioid crisis. With this mission-focused mode, MX908 can identify 70+ common variants of fentanyl at trace levels. Today, first responders are successfully using MX908 on a daily basis in response to this epidemic.

Similarly, MX908 has a built-in CW Hunter Mode making this device uniquely capable of detecting and identifying many other emerging threats. This includes rare chemical warfare agents (CWAs) and novel threat materials.

It's ability to adapt quickly to the priority threats of today makes MX908 unique. MX908 can cover a broad range of threat categories - from the common to the extremely rare - all in one device. There is no other downrange trace detection and identification tool with this level of flexibility.

Read Article

Laser diode mount with integrated heatsink

FROM Wavelength Electronics

Posted: 10 March 2018

Laser diode mount
Laser diode mount with integrated heatsink from Wavelength Electronics.

Wavelength Electronics, has recently released the LDMOUNT laser diode mount designed for 14-pin butterfly laser diodes that require up to 5A. With built-in safety features and easy connection to a range of different high performance Wavelength Electronics controllers the LDMOUNT can be used in a variety of applications.

Features and benefits:

  • Capable of running lasers up to 5A
  • Compatible with 14-pin butterfly laser diode packages
  • Type 1 and Type 2 butterfly packages are supported
  • Zero insertion force (ZIF) sockets holds laser diode
  • Laser interlock safety circuit
  • Mounts to an optical table
  • Compatible with multiple temperature controllers and laser drivers
Read Article

TC15 LAB Series temperature controller

FROM Wavelength electronics

Posted: 10 March 2018

Laser diode temperature controller
TC15 LAB Series laser diode temperature controller from Wavelength Electronics.

Wavelength Electronics has released the TC15 LAB Series temperature control instruments. The TC LAB Series of temperature controller integrates high-end digital control with a precision output current drive stage to offer the best stability temperature control instrument commercially available.

The TC15 (15A, 20V) is an ultra-stable digital controller for thermoelectric and resistive heaters where tight temperature stability is required. Designed using the latest technology, stability better than 0.0009°C can be achieved with thermistors. Wavelength Electronics proprietary IntelliTune™ intelligent tuning algorithm, adapts the PID control coefficients as you change setpoint or tuning mode, always keeping the load optimally controlled. With Wavelength Electronics plug and play instrument you have the ability to quickly set the controls using either the instrument touch screen or a remote computer, and the results are easy to monitor.

Read More

V-408 PIMag linear stage

FROM Physik Instrumente

Posted: 10 March 2018

V-408 PiMag linear stage
V-408 PIMag linear stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched V-408 PIMag magnetic drive compact linear stage.

The PIMag magnetic direct drive does not use mechanical components in the drivetrain, with it's 3-phase magnetic drive transmitting the drive force directly to the motion platform without friction. The V-408 has the following key features:

  • Travel range: 25 and 50mm
  • Resolution: 10nm
  • Minimum incremental motion: 20nm
  • Velocity: 1.5 m/s
  • Bidirectional repeatability: ±100nm
  • Load capacity: 80N
Read More

February 2018

405nm narrow linewidth laser

FROM Cobolt

Posted: 10 February 2018

405nm laser
405nm narrow linewidth laser from Cobolt.

Cobolt, a part of HUBNER Photonics, introduces the Cobolt 08-NLD 405 nm frequency stabilized, Narrow linewidth Laser Diode with up to 30 mW and including an integrated optical isolator. With totally integrated electronics, the compact Cobolt 08-NLD 405 nm is ideally suited for high end Raman spectroscopy or other analytical measurements.

Also available in the 08-01 Series is the Cobolt 08-DPL 532 nm (diode pumped laser), either with or without an optical isolator, Cobolt 08-DPL 561 nm and the Cobolt 08-NLD 785 nm. The Cobolt 08-DPL 532 nm and 561 nm are truly SLM with excellent spectral purity and wavelength stability while the Cobolt 08-NLD 785 nm is a narrow linewidth laser with up to 500 mW.

Read Article

Extended range NIR spectrometer

FROM Stellarnet

Posted: 10 February 2018

Extended range NIR spectrometer
Extended range NIR spectrometer from Stellarnet.

Stellarnet's, high performance RED-Wave-NIRX-SR Spectrometers cover the NIR wavelength range from 900-2300 nm in one unit.

The spectrometers are exceptionally robust with no moving parts and are packaged in small rugged metal enclosure (100 x 152 x 70 mm) for portable, processes, and lab applications. The InGaAs detector is a Sensors Unlimited linear photo diode array with 512 pixels (1024 optional) 25µm by 250µm tall to provide best signal performance. The detector has an integrated two-stage thermo electric cooler (TEC) maintained at -20°C, stabilized within ±0.1°C. The RED-Wave-NIRX-SR-InGaAs spectrometers use single strand SMA 905 fiber optic input.

Applications include chemical absorption, moisture analysis, transmission of filter and optical components and high power radiometric measurements such as laser characterisation.

Read More

P-616 NanoCube multi-axis alignment system

FROM Physik Instrumente

Posted: 10 February 2018

P-616 XYZ stage
P-616 NanoCube multi-axis alignment system from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems has launched the P-616.3C parallel-kinematic multi-axis alignment system.

The NanoCube's parallel-kinematic design offers the highest stiffness in all spatial directions as well as high dynamic motion and resonant frequencies with friction free motion and is highly suited to applications that require fast, precision positioning. The P-616.3C has the following key features:

  • Travel range: 100x100x100µm
  • Resolution: 0.4nm
  • Resonant frequency: 700Hz (unloaded)
  • Dimensions: 40x40x40mm
Read More

December 2017

Quad-PID feedback loop for MFLI lock-in amplifier

FROM Zurich Instruments

Posted: 13 December 2017

MFLI lock-in amplifier
Quad-PID feedback loop for MFLI lock-in amplifier from Zurich Instruments.

Zurich Instruments just added the MF-PID option with 4 independent PID (proportional - integral - derivative) controllers to their MFLI. The MF-PID option builds on class-leading specifications of the MFLI such as low input noise of 2.5 nV/√Hz and a high dynamic reserve of 120 dB. Each controller is seamlessly integrated with the lock-in amplifier, the programmable PIDs enable operation in a wide range of applications such as the setup of phase-locked loops (PLLs) for the phase synchronization of two lasers, CEO stabilization and advanced AFM modes. The maximum control loop bandwidth is 50 kHz.

When setting up a new control loop, the user is well supported by the LabOne PID-Advisor which offers a selection of models that can be picked and adjusted to have a close match with different applications. After defining the target bandwidth, the PID-Advisor suggests a set of parameters and graphically displays the corresponding transfer-function and step-response. Once the feedback loop is running, the auto-tune function optimizes the parameters to minimize the residual PID error. The software toolset included in LabOne also offers a parametric sweeper, oscilloscope and spectrum analyzer. These tools can be used to efficiently analyze the performance of the loop and compare to the selected model. In phase-locked-loop (PLL) mode, phase unwrapping extends the input range to ±1024 π, meaning a reliable feedback at start-up and robust operation throughout.

The MF-PID option can be used in many applications, including frequency combs, frequency-transfer-locks, optical fibre noise-cancellation, atomic force microscopy (AFM), scanning tunneling microscopy (STM), scanning near-field optical microscopy (SNOM), MEMS resonators and gyroscopes.

Read Article

October 2017

C-FLEX laser combiner

FROM Hubner Photonics

Posted: 11 October 2017

Laser combiner
The C-FLEX laser combiner for up to six wavelengths from Hubner Photonics.

Hubner Photonics, a leading manufacturer of laser, terahertz and radar systems has launched the C-FLEX laser combiner.

The C-FLEX is a highly-flexible and extremely compact laser combiner that lets you combine up to six wavelengths from a possible 30 commercially available wavelengths from different laser manufacturers. The lasers can be controlled either separately or via a common USB port. The C-FLEX is field upgradable for when additional lasers are purchased. Individual AOM modulators can be integrated to five of the wavelengths for fast modulation of DPSS lasers. Free space or fiber coupling of the output is available.

Read Article

EnSpectr R1064 Raman Analyser

FROM Enhanced Spectrometry

Posted: 11 October 2017

R1064 Raman analyser
EnSpectr R1064 express IR Raman Analyser from Enhanced Spectrometry.

Enhanced Spectrometry, a manufacturer of portable Raman and luminescent spectrometry solutions for real-time testing and for quality control, announce the release of the EnSpectr R1064 IR Raman Analyser.

The EnSpectr R1064 is a unique instrument that enables the user to obtain Raman spectra in applications where the Raman signal is typically dominated by fluorescence. With the EnSpectr R1064, you can easily analyse, oils, dyes, paints, organic substances, etc. due to its record wide spectral range. It is the only portable 1064nm device which can see the water Raman line. This makes it a comprehensive tool for analysis of liquids through transparent and semi-transparent packaging.

Read More

U-523 and U-723 PILine stages

FROM Physik Instrumente

Posted: 11 October 2017

U-523 and U-723 PILine linear stages
U-523 and U-723 PILine linear stages from Physik Instrumente.

Physik Instrumente, global leader in the design and manufacture of high precision motion control systems has launched the U-523 linear and U-723 XY stages with the PILine ultrasonic piezomotors.

The stages are highly suited to applications that require fast, precision positioning with low duty cycles. The U-523 and U-723 have the following key features:

  • Travel range: 22mm and 22x22mm
  • Velocity: 200mm/s
  • Resolution: 10nm
  • Self locking at rest (no heat generation)
Read More

August 2017

L-731 XY stage

FROM Physik Instrumente

Posted: 4 August 2017

XY stage
The L-731 high performance XY stage from Physik Instrumente.

Physik Instrumente, a global leader in the design and manufacture of high precision motion control systems, has launched the L-731 XY stage. Designed for applications in industry and research the L-731 is a high precision large platform XY stage with non-contact optical encoders that measure the position of the motion platform so that nonlinearity, mechanical play or elastic deformation have no influence on position measuring.

With a travel range of 205 x 205mm, 2-phase stepper or DC motor options and a resolution and repeatability of 50nm and 0.1 m respectively, the L-731 is an industry leading motion control solution.

Read Article

Skyra multi-line laser

FROM Cobolt

Posted: 4 August 2017

Multi-line laser
The Skyra multi-line laser from Cobolt.

Cobolt AB, Swedish manufacturer of high performance lasers, introduces a revolutionary multi-line laser platform, SkyraTM. The SkyraTM can integrate up to four laser lines into a single laser unit.

Unlike laser combiners the SkyraTM is a highly compact (70 x 134 x 38mm), fully integrated multi-line laser that requires no external electronics. The range of laser lines that can be incorporated into the laser are; 405, 445, 473, 488, 515, 532, 553, 561, 633, 638, 647 and 660nm. The individual laser lines can be directly intensity modulated with output powers of up to 100mW each. The SkyraTM is perfectly suited for easy-to-use analytical instruments and application in the life sciences, such as microscopy and flow cytometry.

Read More

High power sub-ns laser

FROM Photonics Industries

Posted: 4 August 2017

High power sub-ns laser
High power sub-ns laser in 1064, 532 or 355nm from Photonics Industries.

Photonics Industries, the pioneer of intracavity solid-state harmonic lasers, has introduced a new SN Series diode pumped solid state laser with high power and sub-nanosecond pulse widths.

The SN Series are designed in a compact, industrial grade all-in-one form factor that integrates the laser and electronics into a single unit with pulse widths from 150ps to 1ns, variable repetition rates from 1kHz to 20MHz and output powers of 70W (1064nm), 50W (532nm) and 25W (355nm). The ability to have the flexibility of sub-ns to 100ps pulse width selection in combination with the highest power commercially available laser uniquely positions the SN series as a solution for a large range of existing and emerging industrial and research applications in material processing.

Read More

June 2017

TC10 LAB series temperature controller

FROM Wavelength Electronics

Posted: 7 June 2017

Temperature controller
The TC10 LAB Series temperature controller is an ultra-stable digital controller for thermoelectric and resistive heaters.

Wavelength Electronics has recently released the TC10 and TC5 LAB Series temperature control instruments. The TC LAB Series of temperature controller integrates high-end digital control with a precision output current drive stage to offer the best stability temperature control instrument commercially available.

The TC10 (10A, 15V) and TC5 (5A, 15V) are ultra-stable digital controllers for thermoelectric and resistive heaters where tight temperature stability is required. Designed using the latest technology, stabilities better than 0.0009 C can be achieved with thermistors. Wavelength Electronics proprietary IntelliTuneTM intelligent tuning algorithm, adapts the PID control coefficients as you change setpoint or tuning mode, always keeping the load optimally controlled.

With Wavelength Electronics plug and play instrument you have the ability to quickly set the controls using either the instrument touch screen or a remote computer, and the results are easy to monitor.

Read Article

Radial polarizer

FROM ARC Optix

Posted: 7 June 2017

Radial polarizer
Radially and azimuthally polarized beams generated from liquid crystal elements.

ARCoptix's Radial Polarizer converts a linearly polarized beam into a beam that has a continuous radial or azimuthal polarization distribution. This unique technology is based on a special alignment of the nematic liquid crystal molecules which are capable of locally rotating the orientation of the linearly polarized laser beam. Either azimuthally or radially distributed polarization is obtained depending on the orientation of the device with respect to the laser polarization.

This device has a working wavelength range from 350 to 1,700 mm, contained in a compact 6 x 4 x 1.5 cm housing with a 10 mm diameter active area. The input/output extinction ratio is ~100 at 633nm. It can be driven with a standard function generator or the ARCoptix USB liquid crystal driver.

Potential applications for the Radial Polarizer include creating Laguerre-Gaussian beams for superresolution microscopy, optical trapping and laser cutting, as well as being a key component for a polarization axis finder system.

Read More

BenchMate vibration isolation platform

FROM Kinetic Systems

Posted: 7 June 2017

Benchmate vibration isolation platform
BenchMate vibration isolation platform from Kinetic Systems.

Kinetic Systems are now offering the BenchMate benchtop based vibration control platform in four different configurations that will suit a range of applications. The BenchMate platforms are designed for high resolution instruments and applications such as; AFM, SPM, interferometers, profilometers and microhardness testers.

Read More

March 2017

C-WAVE tunable laser source

FROM HUBNER

Posted: 16 March 2017

C-WAVE tunable laser
The C-WAVE is a tunable laser light source for continuous wave emission in the visible and near-infrared wavelength range.

Warsash Scientific is pleased to announce the C-WAVE from HÜBNER Photonics, a leading manufacturer of laser, terahertz and radar system solutions. The C-WAVE is a tunable laser light source for continuous wave emission in the visible and near-infrared wavelength range. Its technology is based on optical parametric oscillation (OPO) and is fully computer controlled. It allows you to tune from blue (450 – 525nm) to red (540 – 650nm) and into the near-infrared (900 – 1300nm) without any change of dyes or optical components.

In addition, the use of the AbsoluteLambda software module offers the opportunity for an automated selection of wavelength with high accuracy (set point ±1MHz) and a drift-free wavelength stabilisation (±1MHz) over 12 hours. Control and fine tuning are achieved using intra-cavity elements and piezo-tuning of the cavity length.

Read Article

MSA-100-3D micro system analyser

FROM Polytec

Posted: 16 March 2017

3D laser vibrometer
MSA-100-3D micro system analyser from Polytec.

The MSA-100-3D Micro System Analyzer from Polytec is designed for 3D vibration analysis with high lateral resolution. It is especially suited for microsystems, precision mechanics parts and for studies on the dynamics of HGAs and secondary actuators in the data storage industry.

The instrument is based on a novel 3D vibrometer setup enabling pm-resolution for both out-of-plane and in-plane motion. It has a frequency bandwidth of 25 MHz. An integrated XY-traverse stage with full software support for high-precision sample movement enables scanned measurements for obtaining 3D deflection shapes.

The MSA-100-3D Micro System Analyzer solves many challenging development tasks. Sub-picometer amplitude resolution is achieved for both Out-Of-Plane (OOP) and In-Plane (IP) motion with a small laser spot resulting in high spatial resolution data. This combined with up to 25 MHz bandwidth real time data will open a realm of entirely new applications for the characterization of MEMS and other micro mechanical structures.

Read More

6DOF SpaceFAB

FROM Physik Instrumente

Posted: 16 March 2017

6 degree of freedom motion control
Q-845 Q-Motion based 6DOF SpaceFAB from Physik Instrumente.

Warsash Scientific is pleased to announce the Q-845 from Physik Instrumente (PI), a new parallel kinematic system with a more compact design and higher resolution. Designed for highly accurate positioning with 6 degrees of freedom based on piezo inertia drives.

Read More

January 2017

Helix Si APD

FROM Excelitas

Posted: 16 January 2017

Si APD
The new HeliX Silicon Avalanche Photodiode (APD) Module is a compact, easy-to-use, analogue low-light-level detection module employing Excelitas’ leading-edge Si APD chips.

Excelitas’ new HeliX Silicon Avalanche Photodiode (APD) Module is a compact, easy-to-use, analogue low-light-level detection module employing Excelitas’ leading-edge Si APD chips. The detector is in a hermetic TO package, mounted on a practical OEM based PCB which includes high-voltage power supply, temperature compensation, a low-noise transimpedance amplifier, APD bias monitor and micro-controller.

With this compact voltage-output module, the preamplifier gain is optimized to obtain maximum dynamic range and linearity with the APD at gain adjustable operating voltage. It optimises APD operation in key performance parameters such as higher sensitivity, and better signal-to-noise ratio across the 400nm - 1100nm wavelength range.

Read Article

Sprout-D 532nm pump laser

FROM Lighthouse Photonics

Posted: 16 January 2017

532nm pump laser
Low noise, near-perfect TEM00 mode 532nm pump laser from Lighthouse Photonics.

Lighthouse Photonics announce the release of the updated Sprout-D 532nm high power pump laser. The Sprout-D is a compact, diode-pumped solid-state (DPSS) laser providing up to 12 Watts continuous wave (CW) power at 532nm in a near-perfect TEM00 mode with extremely low optical noise and excellent long-term stability. Sprout-D is truly a next-generation laser designed and manufactured using many years of experience to provide a sealed, turn-key source of collimated green light with high spectral purity. There are 6 versions available ranging from 5 Watts to 12 Watts.

The laser head is a monolithic 3-dimensional design for ruggedness and compactness. The pump diode, integrated inside the laser head, has a typical mean time to failure (MTTF) of more than 50,000 hours to minimize cost-of-ownership. The compact power supply, with touch-screen control, can sit next to the laser head or on an overhead shelf. The laser head can be disconnected from the control cable for easy integration. Additional features of Sprout-D include automatic laser power control and both USB and RS-232 interfaces for external monitoring, control and remote service.

Read More

nanoFTIR imaging and spectroscopy at 10nm resolution

FROM neaspec

Posted: 16 January 2017

nano-FTIR spectroscopy
nanoFTIR imaging and spectroscopy at 10nm resolution from neaspec.

neaspec’s revolutionary technology, neaSNOM is the only microscope on the market capable of imaging and spectroscopy in the visible, infrared and even terahertz spectral region at only 10 nm spatial resolution. The neaSNOM is the ideal tool for cutting-edge nanoanalytic applications such as chemical nano-composition (nano-FTIR-mode), nano-plasmonic fields, nanoscale stress/strain fields and free charge carrier distributions.

The neaSNOM microscope combined with imaging and spectroscopy systems from neaspec thus allow the study of chemical, structural and electronic properties of a sample at a spatial resolution up to 1000-times higher when compared to conventional technology like micro FT-IR. The non-destructive measurement method is equally suited for organic and inorganic samples and requires only standard AFM sample preparation..

Read More
All products and information are subject to change without notice.
